Introduction

In our previous post, we explored the massive potential of combining Enterprise Architecture, Knowledge Graphs, and LLMs. The theory makes sense, but how do we actually build this?

In this second part of the series, we take a deep dive into the practical side: extracting your operational data out of SAP LeanIX and modeling it into Neo4j as a highly traversable graph.

Step 1: Setting up the LeanIX Integration

First, we need to extract our data. To do this, we’ll leverage a CLI tool called dvm-leanix.

You can investigate its capabilities by running the help command locally:

uvx dvm-leanix --help

This reveals standard options for proxying LeanIX:

Options
-------
    --url           LeanIX workspace base URL
    --port          Port to listen on (default: 8765)
    --connect       Chrome DevTools Protocol endpoint to connect to an existing browser

Using this tool, you can easily proxy requests and create a local GraphQL endpoint that interfaces with your LeanIX workspace, giving you a streamlined pipeline to query exactly the data you need.

Step 2: Downloading Factsheets and Relationships

Once your GraphQL endpoint is up and running, you pull the core architectural nodes and edges. In LeanIX terminology, these are called Factsheets (e.g., Applications, IT Components, Business Capabilities) and the Relationships that connect them.

Extracting these allows us to export the data into a structured format (such as CSVs or JSON arrays) which serves as the payload for our Neo4j ingestion. To automate this heavy lifting, we use an integration driver called dvm-eagraph.

We can investigate its capabilities using the help command:

uvx dvm-eagraph --help

Usage
-----
    # Step 1 (one-time): scan your LeanIX workspace and generate the mapping YAML
    dvm-eagraph --generate-mapping

    # Step 2: full run (download from LeanIX + load into Neo4j)
    dvm-eagraph

Step 3: Defining the Graph Model

The most critical part of this integration is the mapping translation. A GraphQL extraction from LeanIX returns data in a typical, nested JSON structure. Our goal is to map this to a Nodes and Relations property schema that makes sense for graph traversal.

For example, LeanIX represents a relationship between an application and a business capability in a verbose manner, such as relApplicationToBusinessCapability.

In our Neo4j model, we want to flatten and clarify this semantic link. We convert that GraphQL relation into a clear Graph edge:

(Application)-[:SUPPORTS]->(BusinessCapability)

Defining clear, real-world verbs (SUPPORTS, DEPENDS_ON, HOSTS) for relationships is what allows a downstream LLM to intuitively reason over the completed graph.

Rather than defining this completely by hand, dvm-eagraph automates this via a generated YAML mapping file:

uvx dvm-eagraph --generate-mapping

This scans your live LeanIX workspace and generates a YAML mapping file that controls which FactSheet types to load and how Neo4j node labels and relationship names are derived automatically based on the rules we just conceptually defined.

Step 4: Converting Data to Idempotent Cypher Scripts

With our model defined and data extracted, we must craft our loading scripts. Instead of simple CREATE statements (which will duplicate data if you run them twice), we need our Cypher scripts to be idempotent. This means they can be run multiple times safely without ruining the graph state.

We achieve this conceptually using the MERGE command in Neo4j. Here is a conceptual example of what that logic looks like under the hood:

// Load the relationships from our extracted export
LOAD CSV WITH HEADERS FROM 'file:///leanix_app_to_bc.csv' AS row

// Find or create the Application Node
MERGE (a:Application { id: row.app_id })
ON CREATE SET a.name = row.app_name

// Find or create the Business Capability Node
MERGE (bc:BusinessCapability { id: row.bc_id })
ON CREATE SET bc.name = row.bc_name

// Create the relationship only if it doesn't already exist
MERGE (a)-[:SUPPORTS]->(bc)

Rather than manually managing these batched queries and CSVs, running the default uvx dvm-eagraph command automatically spins up optimal idempotent transactions based on your mapping file and directly loads the pulled JSON payloads via the LeanIX proxy.

Step 5: Loading the Graph into Neo4j

Finally, you execute your idempotent Cypher scripts against your Neo4j instance.

With the nodes instantiated and the relationships forged, your Knowledge Graph comes to life. What used to be rows in an export or nested JSON objects is now a rich, visual map of your entire enterprise ecosystem.

What’s Next?

Our enterprise logic is now mathematically modeled in a graph database. The next step? Giving it a proxy to speak!

In our next follow-up, we will explore Connecting Neo4j to Copilot (or Claude), detailing how to utilize the Model Context Protocol (MCP) to let your AI agents query your new architecture graph in natural language.
